Description
Specifications
Optical
Light Source: 16 LEDs (quad-color RGBW) 45 W, (3.0 A), 8875 K, 50,000 hours life expectancy.Color Temperature (calibrated white): 6122 KCRI: 61.6Beam Angle: 5.8° to 30.4°Beam Angle single cell: 4° to 29.9Field Angle: 8.9° to 42.2°Field Angle single cell: 5.4° to 42.3°Cutoff Angle: 10° to 47.9°Cutoff Angle single cell: 6.1° to 45.5°Zoom Range: 5.8° to 47.9°Zoom Range single cell: 4° to 45.5°Lumens (43.3°): 8,959Illuminance (5.7°): 27,415 lux @ 5 mIlluminance (43.3°): 1,294 lux @ 5 mSelectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
Tilt: 200°Tilt Ranges: 60°, 180°, 200°Dimmer: ElectronicShutter/Strobe: ElectronicZoom: MotorizedStrobe Rate: 0 to 20 HzDim Modes: 2Dim Curves: 4
Construction / Physical
Dimensions: 39.37 x 5.47 x 10.75 in (1000 x 139 x 273 mm)Weight: 45.6 lb (20.7 kg)
Exterior Color: BlackHousing Material: Aluminum alloy, Aluminum diecast, High-impact flame-retardant polymer
Connections
Power Connection: Bare end to Seetronic Powerkon IP65Power Input: Seetronic Powerkon IP65Power Output: Seetronic Powerkon IP65Data Connectors: 5-pin IP rated, Seetronic IP rated RJ45 Connectors in/outCable Length (power): 5 ft (1.5 m)
Control
Control Protocol: Art-Net, Kling-Net, DMX, RDM, sACN
Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)Fuse: 12 A, 250 VPower Linking: 0 unit @ 120 V; 3 units @ 208 V; 3 units @ 230 VPower and Current: 790 W, 6.60 A @ 120 V, 60 HzPower and Current: 771 W, 3.821 A @ 208 V, 60 HzPower and Current: 768 W, 3.485 A @ 230 V, 50 Hz
Certifications / Qualifications
CE, MET, FCCIP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valveTemperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
