PCE Distribution Box 32A 240V In, 4 x 16A + 1 x 32A 240V Out

Description

These PCE IMST distribution boxes are handy, robust, lightweight and made of shock-resistant polyamide. They feature a high-grade steel folding carry handle, have stackable design and are IP44 rated.

– Handy, robust and lightweight distribution box made of shock-resistant polyamide
– High-grade steel folding carry handle
– 5 modules under clear MCB window
– IP44 rated
– Stackable design
– Made in the EU

– Input: 32A 220-250V~50/60Hz 3-Pin 2P+E IP44 inlet
– Outputs: 1 x 32A 220-250V~50/60Hz 2P+E IP44 socket,4 x 16A 220-250V~50/60Hz 2P+E IP44 sockets each protected by 16A 1P MCB type C
– 32A 30mA 2P RCBO protecting all outputs
– Dimensions: 196 x 245 x 300mm
