Wireless Solutions Blackbox F-2 G6 Wireless DMX Transceiver

Description

PERFORMANCE
Transmitter & Receiver modes
Up to 700 meters / 2,200 feet
1,024 DMX channels
TECHNICAL SPECIFICATIONS
2.4 GHz
DMX and RDM
Art-Net & Streaming ACN (with optional WiFi)
Bluetooth
Adaptive Frequency Hopping
Data-Safe
Backward compatibility with G3, G4, G4S, and G5 series
Option for CRMX compatibility
Compatible with all OEM products
The G6 series is not compatible with the W-DMX™ Dongle
Supports the W-DMX™ Configurator App

The Blackbox F-2 G6 is a simple and reliable RDM and Wi-Fi transmitter, receiver and repeater. This allows you to create a solid wireless connection up to a distance of 700 metres (2200 ft). You can send / receive / repeat up to 512 DMX channels with it. In addition, it can be used in combination with previous generations, such as the G3, G4, G4S and G5. If you want to connect the Blackbox F2 G6 to a Lumens Radio CRMX transmitter, you can opt for the optional CRMX upgrade for F2 G6. This makes this receiver box the first in the world to work with more than two million wireless DMX units.
The Blackbox F-2 G6 is an advanced device, yet very easy to control with just one button and status indication LEDs. You can also easily perform updates via Bluetooth using the W-DMX Configurator app. The aluminium housing has a built-in M10 clamp mount and hole with which it can be securely attached with hook and loop and an extra security thread.
Carrier Frequency 2,4 GHz
Gain (mW) 100 mW
Reaction Time 5 ms
Antenna Boost 3 dBi
Antenna Type Omni
Length (mm) 235 mm
Width (mm) 150 mm
Height (mm) 45 mm
Weight 1 kg
Rack Units 1 U
IP Rating IP42
Material Aluminium
Housing Aluminium die-cast
